About These Drawings

The following images I've painstakingly created to provide reference information as to where basic amenities and common things people inquire about on VIA Rail trains are. It is my goal to have all current, at the time of writing, VIA Rail revenue equipment shown here. However, I've not finished making them, as each drawing takes a few hours to do.

Icon Key

Coming Soon!

Corridor Fleet

HEP2 Cars

The HEP2 cars are a series of single-level passenger cars with Head-End Power (HEP) that were originally built by Budd. VIA Rail acquired them from Amtrak and refurbished them for its Corridor fleet, where they provided reliable and comfortable service for intercity travel for decades.

HEP2 Galley Business Car

The HEP2 Galley Business Car offers enhanced amenities for business class passengers, including a dedicated galley for food and beverage service, providing a comfortable and productive travel environment on Corridor routes.

HEP2 Galley Business Car
Return to Top

HEP2 Economy Car

HEP2 Economy Cars are modern coaches designed for comfortable and efficient travel on VIA Rail's Corridor services, featuring updated interiors and passenger amenities.

HEP2 Economy Car
Return to Top

Venture Cars

The Venture fleet, built by Siemens, represents the newest generation of single-level push-pull trainsets for VIA Rail's Corridor service. They are replacing the aging LRC and HEP2 fleets to provide modern, high-quality service.

Venture Coach Car

The newest generation of single-level coaches for VIA Rail, designed for modern comfort and efficiency on various routes.

Venture Coach Car
Return to Top

Venture Business Car

Venture Business Cars offer premium seating and services, representing the latest in VIA Rail's business class offerings.

Venture Business Car
Return to Top

Venture Cab Car

Venture Cab Cars are equipped with a control cab at one end, allowing for push-pull operations. They offer premium seating and services, representing the latest in VIA Rail's business class offerings.

Venture Cab Car
Return to Top

LRC Cars

The LRC (Light, Rapid, Comfortable) cars, built by Bombardier, were originally designed and built in Canada for high-speed tilting operations. They were the primary intercity passenger cars for the Quebec City-Windsor Corridor for many years before being replaced by the newer Venture fleet.

LRC Economy Car

LRC (Light, Rapid, Comfortable) Economy Cars were a significant part of VIA Rail's fleet, designed for high-speed intercity travel, primarily in the Quebec City–Windsor Corridor. These cars were known for their tilting mechanism, which allowed them to navigate curves at higher speeds, and offered comfortable seating for passengers.

LRC Economy Car
Return to Top

LRC Club Car

LRC Club Cars provided enhanced service and comfort for passengers in the Corridor fleet, offering a more exclusive travel experience with dedicated amenities and seating.

LRC Club Car
Return to Top

RDC Cars

Rail Diesel Cars (RDC), built by the Budd Company, are self-propelled diesel multiple units that were historically used by VIA Rail on various local and regional routes. They were a flexible and efficient solution for passenger service, known for their ability to operate without a separate locomotive.

RDC-1

RDC-1 (Rail Diesel Car) is a self-propelled diesel multiple unit, primarily used for passenger service on routes where a full locomotive-hauled train is not required. It features seating for passengers and a cab at each end for bidirectional operation.

RDC-1
Return to Top

RDC-2

RDC-2 cars are similar to RDC-1s but include a baggage compartment in addition to passenger seating, making them versatile for routes requiring both passenger and light freight capacity.

RDC-2
Return to Top

Long Distance Fleet

Renaissance Cars

The Renaissance fleet, built by Alstom, consists of single-level passenger cars acquired from the UK. These cars are used on VIA Rail's long-distance routes, such as the "Ocean," providing a distinct European-style travel experience with a variety of service classes.

Renaissance Coach Car

Renaissance Coach Cars were acquired from the UK and adapted for Canadian service, offering a distinct single-level passenger experience with comfortable seating on long-distance routes.

Renaissance Coach Car
Return to Top

Renaissance Sleeping Car

Renaissance Sleeping Cars provide private accommodations for overnight journeys on long-distance routes, including various room types for different passenger needs.

Renaissance Sleeping Car
Return to Top

Renaissance Service Car

Renaissance Service Cars are dedicated to providing on-board services, which may include food preparation, storage, or crew facilities, supporting the passenger experience on long-distance trains.

Renaissance Service Car
Return to Top

Renaissance Club Car

Renaissance Club Cars offer enhanced comfort and service for premium passengers on long-distance routes, featuring more spacious seating and at-seat service.

Renaissance Club Car
Return to Top

Renaissance Dining Car

Renaissance Dining Cars offer full sit-down meal service on long-distance routes, providing a complete dining experience for passengers.

Renaissance Dining Car
Return to Top

HEP1 Cars

The HEP1 fleet consists of modernized Heritage Fleet cars, a collection of classic stainless steel cars originally built in the 1950s by Budd for Canadian Pacific's prestigious 'The Canadian' train. They were extensively rebuilt and equipped with Head-End Power (HEP) to extend their service life, and are a key component of VIA Rail's long-distance service.

HEP1 Coach Car

HEP1 Coach Cars are part of the modernized Heritage Fleet, offering comfortable seating for long-distance journeys with updated amenities.

HEP1 Coach Car
Return to Top

HEP1 Manor Sleeping Car

HEP1 Manor Sleeping Cars are part of VIA Rail's classic fleet, offering a variety of private accommodations including bedrooms and roomettes, often named after Canadian manors, with modernized systems.

HEP1 Manor Sleeping Car
Return to Top

HEP1 Chateau Sleeping Car

HEP1 Chateau Sleeping Cars are another type of modernized sleeping car in VIA Rail's classic fleet, known for their distinct room configurations and often named after Canadian chateaus.

HEP1 Chateau Sleeping Car
Return to Top

HEP1 Skyline Dome Car

HEP1 Skyline Dome Cars provide excellent viewing opportunities on long-distance routes with their iconic dome sections, often including a small cafe or lounge area.

HEP1 Skyline Dome Car
Return to Top

HEP1 Park Car

HEP1 Park Cars are iconic dome cars, typically found at the rear of long-distance trains, offering panoramic views from the upper level and various lounge areas below, all with modernized systems.

HEP1 Park Car
Return to Top

HEP1 Dining Car

HEP1 Dining Cars offer full meal service on long-distance routes within the modernized Heritage Fleet, providing a classic dining experience.

HEP1 Dining Car
Return to Top

Other Cars

This category includes a variety of specialized cars that are used on VIA Rail's long-distance services, each designed to provide unique and exceptional passenger experiences.

Panorama Car

The Panorama Car is a unique viewing car offering expansive panoramic windows for an unparalleled scenic experience on select long-distance routes.

Panorama Car
Return to Top
